HIGH MAST POLE

SEND INQUIRY

HIGH MAST POLE


Poles height

12m to 40m

Shape

Round conical; Octagonal tapered; Straight square; Tubular stepped;Shafts are made of steel sheet that folded into required shape  and welded longitudinally by automaticarc welding machine

Material

Q235,Q345,Iron,Stell,Aluminum

Brackets/ Arm

Single or double brackets/ arm are in the shape and dimension as per customers requirement

Welding

It has past flaw testing.Internal and external double welding makes the welding beautiful in shape.And confirms with international welding standard of CWB,BS EN15614

Thickness

1.8mm-20mm

surface treatment

Hot dip galvanization with thickness of 80-100µm average in accordance with Chinese standard GB/T 13912-2002 or American standard ASTM A123, IS: 2626-1985.BS EN ISO 1461

Base plate mounted

Base plate is square or round in shape with slotted holes for anchor bolt and dimension as per customers requirement.

Wind resistance

Customized,according to customer's environment

Powder coating

Pure polyester powder painting, color is optional according to RAL Color stardand.
